pdx:addMathEquation
Inserts a math equation in OMML or MathML format.
Note
You are reading the XML API documentation. For the PHP API method please go to addMathEquation.
Description
Element definition
6
1
<pdx:content>
2
<pdx:addMathEquation pdx:type="docx|omml|mathml" pdx:wordFragmentName="" pdx:align="left|center|right" pdx:color="" pdx:bold="" pdx:fontSize="" pdx:italic="" pdx:underline="">
3
<pdx:data pdx:dataId="" pdx:dataType="text">path to docx|<![CDATA[OMML code]]>|<![CDATA[MML code]]></pdx:data>
4
</pdx:addMathEquation>
5
</pdx:content>
6
Adds a math equation to the DOCX.
Attributes and sub-elements
equation
The OMML equation code.
type
The equation type: docx, omml or mathml.
align
left, center, right
bold
color
ffffff, ff0000...
fontSize
8, 9, 10...
italic
underline
single...
Code samples
config.xml
content.xml
14
1
2
<pdx:document xmlns:pdx="http://www.phpdocx.com/main">
3
<pdx:content>
4
<pdx:addText>
5
<pdx:textRun>
6
<pdx:data pdx:dataId="" pdx:dataType="text">Extract a math equation from an external Word file:</pdx:data>
7
</pdx:textRun>
8
</pdx:addText>
9
<pdx:addMathEquation pdx:type="docx">
10
<pdx:data pdx:dataId="" pdx:dataType="text">/var/www/phpdocx/samples/files/math.docx</pdx:data>
11
</pdx:addMathEquation>
12
</pdx:content>
13
</pdx:document>
14
settings.xml
PHP code
